Small Volume Single Output 1000W Switching Power Supply 12V 80A Transformer AC110V or 220V TO DC SMPS for LED Light CNC Stepper

Small Volume Single Output 1000W Switching Power Supply 12V 80A Transformer AC110V or 220V TO DC SMPS for LED Light CNC Stepper
  • Продавецphiladelphiaeaglesvscarolinapanthers.us
  • Список ценUS $59.99piece
  • Продажная ценаUS $59.99piece
  • ДоставкаБесплатная доставка
  • Рейтинги3,7 (537)

Oписание продукта








Feature:

Using microprocessor (MCU) control

High power density, small and beautiful appearance

Full metal housing, very low electromagnetic interference

Using the encoder to adjust the voltage and current, set the fast and accurate

Four digital voltmeter and ammeter, set and display exactly two digits after the decimal point

Active power factor correction (Active PFC), rated output power factor> 97%;

High efficiency, efficiency up to 90%

Low ripple noise, ripple peak is less than 30mV

Output ON / OFF switch

Intelligent protection: output short circuit protection, tracking overvoltage protection (Tracking OVP), tracking overcurrent protection (Tracking OCP), over temperature protection (OTP)


Specifications:

Operating voltage range 170 - 264Vac
Operating frequency range 45 - 65HZ
Output voltage range 0 - 60V
Output current range 0 - 17A

Power factor ≥ 97%
Efficiency (220Vac, full load) ≥ 89%
Full load input current (220Vac) ≤5.1A
No-load input current (220Vac) ≤ 180mA
Voltage meter accuracy ≤ 0.3% + 1 digits
Ammeter Accuracy ≤ 0.3% + 2 digit

Constant pressure state
Load regulation rate (0-100%) ≤ 30mV
Input voltage regulation rate (198-264Vac) ≤ 10mV
Ripple noise (Peak-Peak) ≤ 30mV
Ripple noise (r.m.s) ≤ 3mV
Set the accuracy of ≤ 0.3% + 10mV
Transient response time (50% -100% rated load) ≤ 1.0ms

Constant current state
Load regulation (90% -10% Rated Voltage) ≤ 50mA
Input voltage regulation rate (198-264Vac) ≤ 20mA
Ripple current noise (peak-to-peak) ≤ 30mAp-p
Set the accuracy of ≤ 0.3% + 20mA
Size (width × height × depth) 188 × 80 × 238mm
Net weight 3.0KG
